High Capacity Tilt Table

The High Capacity Tilt Table has been specifically designed for bariatric use. Unique in its design, it is the only Tilt Table available capable of safely lifting and tilting up to 350kg and allows the patient to walk on and walk off the bed using the electrically operated plantar/dorsiflexion footplate which meets flush with the floor minimizing any tripping hazard.

  • High Low 650mm – 950mm
  • Tilt function from 0 – 85 degrees
  • Independent tilt & height adjustment
  • No horizontal movement when raising
  • Easy to move on 4 x locking castor wheels
  • Extremely stable
  • Dorsiflexion + / – 10% electric footplate – 300mm
  • Dunlop Enduro 50mm foam
  • 350kg weight capacity
  • Dimensions 1950mm (L) x 1000mm (W)

The Tilt Table is supplied with 3 adjustable patient straps, twin multi-function hand switches and side locking castors. It is also available with an optional digital weighing system accurate to 0.1kg.

Click here to see a pdf file with specifications & dimensions


  • Electric height & tilt adjustment with hand switch
  • Single foldaway footplate as standard
  • Optional +/- 10º plantar/dorsi footplate available
  • Three patient safety straps supplied as standard
  • Footplates can foldaway converting the tilt table into an examination table when required
  • Independently operated tilt & height adjustment can be operated at the same time or individually from any position
  • Central locking castors
  • 150mm clearance to accommodate patient lifter
  • Digital weighing scales built into frame
  • Castor legs at tilt end are wide enough to fit a walking frame
  • Australian designed & manufactured
  • 5 year warranty on electrics
  • Lifetime structural warranty
