HT Tilt Table – Slide Top


Ideal for Rehabilitation Wards, Diagnostic Clinics doing veinous testing or Physiotherapy the sliding top allows patients to practice exercises actively.

Standard Table Pricing Only, see options and accessories below to customise your table.

Suitable for a broad spectrum of patients where decreased leg strength is a problem, the advantage of having a sliding top allows the patients to increase their strength and endurance safely.

Patients are able to practice independently or with carers and allows active practice for patients undertaking any rehabilitation programme.


  • Electric Height and Tilt Adjustment with Hand Switch
  • Patient Lifter Access with Clear Span Base (Low Height Base model also available – Product Code: 50831T-70-LH)
  • Split Foot Plate
  • +/– 10º Plantor/Dorsi Flexion Foot Plates
  • FootPlates can foldaway converting the Tilt Table into an Examination Table when required
  • FootPlates can allow for Single Leg Squats to be performed
  • Removable and Adjustable Shoulder Horns for Premium Posture Support
  • Friction Free Slide Top can be Locked in Various Positions
  • 3 x Patient Safety Straps Supplied as Standard
  • Independently Operated Tilt and Height Adjustment – can be Operated at the same time or Individually from Any Position
  • Infinite Tilt Adjustment to +75º
  • Inclination Indicator to Measure Tilt Angle
  • Heavy Duty Industrial Lockable Castors
  • Australian Designed and Manufactured
  • Warranty (Parts Only) – 10 Year Structural on base and frame – 5 Year Electrical – 3 Year Upholstery
Maximum Working Load400kg (Stationary)
Maximum Lifting Capacity200kg (Moving)
Minimum Working Height550mm
Maximum Working Height 1000mm
Table Width710mm
Table Length2000–2400mm
Cushioning50mm Foam
ControllerHand Switch
Base/CastorX-Frame Base w/independently Lockable Castors 360º Rotation
Tilt AngleElectric Adjustment +75º
